XMLMarker Class Reference
[XML Marker]

#include <XMLMarker.h>

Inheritance diagram for XMLMarker:

List of all members.

Public Member Functions
	XMLMarker (XMLMarker *, QString nsp, QString nom, QXmlAttributes xml)
virtual	~XMLMarker ()
XMLMarker *	getParent (QString)
virtual void	printMe ()
virtual void	characters (QString s)
virtual bool	endXMLMarker ()
QString	getName ()
virtual bool	isValidDescendant (QString s)
virtual bool	getStatus ()
Static Public Attributes
int	nbinstance = 0
Protected Attributes
QString	nom
QString	error
bool	status

---

Detailed Description

This class represent the marker that are piled in the musicXMLParser when reading of the MusicXML Files. It should be inherited by every marker. Here are the actions to perform to add a new marker

• Create the class marker or put the code in a semanticly correct filename
• Implements the Contructor
• Implements void characters(QString s);
• Implements bool endXMLMarker();
• Add the marker int he musicXML factory You're done

---

Constructor & Destructor Documentation

XMLMarker::XMLMarker (  XMLMarker *  p, QString  nmsp, QString  n, QXmlAttributes  xmlatts )

The status field is used to say if everything went correct Parameters: p  The parent : Each Marker according to the DTD can only have a little set of parents.

XMLMarker::~XMLMarker (   )  [virtual]

Destructor of the XML marker

---

Member Function Documentation

QString XMLMarker::getName (   )

Returns: the name of the emelent

XMLMarker * XMLMarker::getParent (  QString   )

Diplay a short descritpion of the marker

bool XMLMarker::getStatus (   )  [virtual]

This method is called after the building of one element to see if it is worthy to go on *

bool XMLMarker::isValidDescendant (  QString  s  )  [virtual]

This method is called to check if it is possible to build the descendant whose name is s In a sense it does the same thing like an XML validating parser. But since I know what can do my implementation that what MusicXML allow I prefer to code it Be aware that this is not always implemented since I'm lazy, made it possible because it note virtual voi method Parameters: the  name of the descendant Reimplemented in Alter, Attributes, Backup, Lyric, Measure, Notations, and Pitch.

---

The documentation for this class was generated from the following files:

• XMLMarker.h
• XMLMarker.cpp

---
